Transport and occasional order picking is more ergonomic, safer, and quicker
The pallet truck with order picking lift T16 L makes handling and occasional order picking easier. The operator lifts the pallet to a comfortable height and can then deposit or load the goods. In addition, the truck adapts this lift automatically with the optional AutoLift function. The load height for the operator thus remains the same even when goods are stacked on the pallet. A rugged steel construction protects the truck from damage during tough, continuous use. The low chassis covers the wheels and protects the operator's feet. The powerful three-phase motor provides good acceleration, even with the maximum load of 1600 kg. At the maximum lift height, the truck has a residual load capacity of 800 kg.
Characteristics
Safety
The low chassis covers the wheels and protects the operator's feet. The extra long tiller of the T16 L is mounted at a low point on the truck. This creates a safe distance between the operator and the truck when it is moving. The tiller head offers additional safety, because it completely surrounds the driver's hands. The SafetySpeed function is available as an option. It adjusts the speed to the tiller position - the higher the tiller, the slower the speed. This increases safety in tight spaces.
- Deep-drawn chassis for foot guard
- SafetySpeed Function
- Tiller with hand protection
- Low tiller mounting point
Ergonomics
The order picking lift of the T16 L eliminates the need for the operator to kneel down or bend their back during loading. There are switches on both sides of the truck to easily control this lift. The truck automatically adjusts to the order picker using the optional AutoLift. The loading height remains ideal for the operator even when the goods are stacked high on the pallet. The T16 L has deep storage compartments offering plenty of convenient stowage space for work materials.
- Easily controllable order picking lift
- AutoLift for automatic picker adjustment
- Deep storage compartments
Handling
The powerful three-phase motor accelerates the pallet truck quickly to a top speed of six kilometers per hour – both with and without a load. The truck can also manage gradients even with a full load. The motor can also achieve a higher torque with the booster effect when difficult situations need to be dealt with. The residual load capacity is still 800 kg at maximum picker height. Broad masts ensure stable transport.
- Powerful three-phase motor
- High residual load capacity
- Broad masts for more stability
- Booster effect for a higher torque
Service
The materials used ensure greater stability and reduced repair coasts: The mast and fork carriage are made of high-quality, strong steel. The tiller and motor cover are made of particularly tough, fiberglass-reinforced, materials. This construction absorbs a lot of impacts and bumps during tough, continuous use. Rapid service processes are guaranteed by the CAN bus connection. The service technician connects their laptop and then performs a rapid truck diagnosis. All of the service components of the T16 L are easy to reach.
- Rugged construction for low service costs
- CAN bus structure
- Easily accessible service components
Technical Data
| Model | Load capacity/Load | Lift | Travel speed, with/without load | Turning radius | Battery voltage/rated capacity (5h) |
|---|---|---|---|---|---|
| T16L | 1.6 (t) | 675 (mm) | 6 / 6 km/h | 1625 / 1685 (1550 / 1610) (mm) | 24 / 250 (24 / 150) (V)/(Ah) o. kWh |
| T16L ION | 1.6 (t) | 675 (mm) | 6 / 6 km/h | 1625 / 1685 (1550 / 1610) (mm) | 24 / 205 (V)/(Ah) o. kWh |
Optional Equipment
-
Acoustic signal
-
Foot Guard
-
Integrated Charger
-
Cold store protection
-
Lithium-ion technology
-
Load backrest
-
Emergency stop button
-
AutoLift
-
Proportional Speed
-
Creep speed button
-
Side lift buttons
-
Access control
Acoustic signal
The optional buzzer sounds different from the standard horn and can be heard better in loud environments.
Foot Guard
The lifting movement of the fork stops automatically in its bottom position. This function protects the operator's feet.
Integrated Charger
The intregrated truck charger increases flexibility: The pallet truck can be charged nearly everywhere and at any time.
Cold store protection
In this version, the user can operate the pallet truck at external temperatures down to -35 degrees Celsius.
Lithium-ion technology
With Linde's innovative lithium ion batteries, trucks can be recharged in a much shorter time and intermediately charged during operation.
Load backrest
The backrest stabilizes the load and prevents the pallets from sliding.
Emergency stop button
If the operator hits the button, the truck stops immediately, protecting them and others from hazards or damage.
AutoLift
Sensors on the truck automatically adjust the order picking lift during loading. The load height for the operator thus remains the same even when goods are stacked on the pallet.
Proportional Speed
This function automatically adjusts the speed depending on the tiller position; the more vertical, the slower it goes. This means the truck cannot bump against the operator.
Creep speed button
The truck moves slowly when the operator activates the button, even when the tiller is in the vertical position. This makes maneuvering easier in tight spaces.
Side lift buttons
The operator controls the lifting and lowering functions using buttons on the side of the chassis.
Access control
Access control of the connect: fleet management software from Linde informs the fleet manager or warehouse manager who is at the wheel of which truck. The driver must identify themselves using a PIN or a RFID card before they can start the truck.
