Fast Transport Even in Confined Spaces

The electric tow tractors P40 – P60 C are compact and maneuverable towing vehicles which are particularly suitable for indoor transport and line supply in production. Thanks to a wide range of trailer couplings, the P40 – P60 C are compatible with a wide variety of trailer types. The special design of the vehicles allows the driver an optimum view of the trailer and load. The design is very ergonomic: the dashboard, backrest and driver’s platform are decoupled from the chassis and absorb shocks and vibrations. The ergonomic and intuitive Linde steering wheel is height-adjustable and can be adapted to the driver’s needs.

Characteristics

Safety

The electric tow tractors P40 – P60 C are designed so that the body and limbs of the driver remain within the protective vehicle contour at all times. The robust cast steel bumper protects the driver and vehicle in the event of a collision. When cornering, the tractor automatically reduces its speed. The P40 – P60 C can be equipped with LED front and rear lights, turn signals, work lights, and brake lights that illuminate the driver’s area of vision or improve the visibility of the vehicle in operating traffic. Linde BlueSpot™is also available as an option.

  • Chassis construction protects driver
  • Robust steel bumper
  • Extensive lighting systems – optional
  • Reduced speed in curves
  • Access control via Linde connect

Ergonomics

The ergonomic design of the electric tow tractors P40 – P60 C enables the driver to work without fatigue. The vehicles have an individually adjustable backrest with fold-out seat and a spacious driver’s platform. The control elements on the Linde steering wheel are easy to reach and intuitively arranged. The driver’s seat and steering wheel can be adjusted to suit their size. A wide entrance with low step height simplifies getting in and out. The dashboard, backrest, and driver platform are fully suspended, protecting the driver’s body from shocks. Spacious storage compartments allow the driver to safely stow and quickly reach all work utensils.

  • Adjustable backrest with folding seat
  • Spacious cabin with plenty of legroom
  • Wide entrance with low step height
  • Fully suspended driver’s platform
  • Generous storage compartments for work utensils

Handling

The P40 – P60 C offers a towing capacity of 4 to 6 tonnes. Thanks to the powerful and low-maintenance 3 kW engine (2.3 kW with P40 C B) they reach a top speed of 13 km/h without load. The chassis gives the driver an excellent view of the trailer and load. A wide selection of different trailer couplings makes the electric tow tractors compatible with many different trailer types. The height-adjustable Linde steering wheel can be effortlessly operated with one hand and allows the driver to perform precise maneuvers in any direction. The P40–P60 C can also be equipped with innovative lithium-ion batteries from Linde Material Handling.

  • Powerful motor
  • Good view of trailer coupling and load
  • Wide range of trailer couplings
  • Precisely operable Linde steering wheel

Service

The robust design of the electric tow tractors P40 – P60 C enables very long maintenance intervals and thus ensures a high availability of the vehicles. The drive wheel can operate for 10,000 hours before re-lubrication is required with no need to readjust the brakes. Non-contact sensors do not wear out. In order to carry out service work effortlessly, all important components of the vehicle are easily accessible and the cable harnesses are clearly arranged.

  • Robust, low-maintenance design
  • High vehicle availability
  • Wear-free sensors
  • Main components are easily accessible

Technical Data

Model Load capacity/Load Overall width across chassis Travel speed, with/without load Turning radius Battery voltage/rated capacity (5h)
P40C 4.0 (t) 8 / 13 (km/h) 1229 (mm) 24 / 360/465 (V)/(Ah)
P40C B 4.0 (t) 8 / 10 (km/h) 1229 (mm) 24 / 360/465 (V)/(Ah)
P60C 6.0 (t) 8 / 13 (km/h) 1229 (mm) 24 / 360/465 (V)/(Ah)

Optional Equipment

The suspension of the driver’s platform of the P40–P60 C from Linde Material Handling protects the driver against vibrations and shocks.

Driver’s Platform with Adjustable Suspension

The suspension of the driver’s platform can be adjusted according to the driver’s weight. The driver is thus always optimally protected against vibrations and shocks.

The backrest of the P40–P60 C from Linde Material Handling can be adjusted individually.

Adjustable Backrest

The backrest can be individually adjusted to the needs of the driver. A folding seat provides additional comfort and fatigue-free working.

The front bumper of the P40–P60 C from Linde Material Handling protects the driver in the event of a collision.

Bumper Options

There are many extensions available to further improve the protective function of the front bumper. In the event of a collision, the chassis and driver are now even better protected.

The steering wheel of the P40–P60 C from Linde Material Handling can be individually adjusted.

Adjustable Steering Wheel

The height of the steering wheel can be adjusted to suit the size and position of the driver allowing for even more ergonomic working.

The electric tow tractor P40–P60 C from Linde Material Handling can be equipped with a trailer hitch.

Trailer Hitch

If required, Linde can equip the vehicle with a 1-stage or 3-stage coupling. Also available is a manual remote release, which is operated from the driver’s seat by cable, as well as special couplings for route trains.

Pedestrian operation of the P40–P60 C from Linde Material Handling enables an operation outside the truck.

Pedestrian Operation

Push buttons are located on both sides of the truck. They allow the driver to operate the tow tractor from the outside and walk alongside at the same time. The pedestrian operation allows the driver to move the vehicle comfortably without having to climb up again for short distances.

The electric tow tractor P40–P60 C from Linde Material Handling can be equipped with different LED lighting options.

Lighting Equipment

On the front and rear, the vehicle can be equipped with different LED lighting options that significantly improve visibility and safety.

Acoustic Warning Signal

The signal can be heard when the vehicle is moving, warning pedestrians and other vehicles.
